LCBB series of heavy duty disc harrow was designed according to the Europe standard .it adopts the features on hydraulic offset modular structure, built-bearing composite design, reasonable structure, bearing seal, long life, durable, easy to transport, easy to adjust, and easy maintenance. This heavy duty harrow also can be used to clean the stubble before tillage, break the hardened and impervious soil surface, crush and spread straw into the field, shatter soil after tillage, and level the land and preserve soil moisture. It can be used as tillage machine instead of plow on the cultivated land.
It is a trailed hydraulic offset disc harrow for 80-200hp tractor such as YTO,JOHNDEER tractor.
This hydraulic trailed heavy disk harrow is designed in the standard, of Europe.
With high strength, good seal, the advantages of long life products.
More strong harrow frame and to be in long working life.
Unique design of bearing assembly can keep good seal.
The disc blades are for 65Mn steel and the diameter of plough disc can be 710x8mm.
| Model || Unit || LCBB-2024 || LCBB2428 || LCBB2834 |
| Working width || mm || 2400 || 2800 || 3400 |
| Working depth || mm || 200/240 || 200/240 || 200/240 |
| Q’ty of disc || || 20 || 24 || 28 |
| Tires || || 7.50-16/11L-15 || 7.50-16/11L-15 || 11L-15/400/60-15.5 |
| Total weight || kg || 1800/2000 || 2100/2350 || 2400/2700 |
| Matched power || hp || 80-120 || 120-160 || 160-200 |
| Linkage || || Trailed(trailed hole diameter 38mm) ; |
Hydraulic output 1 type(difunctional oil cylinder),oil connection in 1/2” thread
The items selectable
| || |
710*8 disc blade; oil connection (M22*1.5/M20*1.5/M18*1.5)
