This corn no-tillage seeder is used for planting corn, soybean; It is applicable to fertilizer and seed in the plains and hilly areas. There are two containers for seeds and fertilizer respectively. This corn planter is suitable for 15-100hp 4wheel tractor, the unique design of plow point to make the better plowing effect. Rubber-tired tire is more durable.
The gears are connected by chains; at the bottom are wheels rolling on the ground, with the features of Seeding uniformity, high working efficiency, saving seeds, and the depth of seeding can be regulated and controlled, the row spacing is stable.
This corn seeder is seeding the corn seed uniformity.
The seeding depth of the maize fertilizing seeder can be regulated and controlled.
Stable row spacing for this mounted corn planter.
It is a mounted corn/maize planter cum fertilizer for 15-80hp tractor.
| Model || Unit || 2BYF-3A || 2BYF-4A || 2BYF-5A |
| Working depth || mm || 50-100 |
| No., of seeding row || || 3 || 4 || 5 |
| Row spacing || mm || 500-620 |
| Planting distance || mm || 200-250 |
| Matched power || hp || 25 || 40 || 50 |
| Total weight || kg || 190 || 255 || 320 |
| Linkage || || Three-point suspension I type || |
Three-point suspension II type
The items selectable
| || the max row spacing 700mm adjustable, |
(row spacing could be adjusted ,but no plating distance)
